Oscilloscope Model EI 803 - 30 MHz
SKU PH1294C
Microcontroller based oscilloscope, gives you feel of smooth digital touch.
Microcontroller based oscilloscope, gives you feel of smooth digital touch. Digital readout backlit LCD displays Volts/Div. and Time/Div. settings when these controls are operated. Light weight and have sharp and bright trace. Vertical bandwidth is more than adequate and you can view signals up to 50MHz. The four trace features allows you to view original and expanded signals simultaneously for quick analysis.30 MHz BandwidthSharp Trace CRT and Auto focusComponent and Continuity TesterStable Triggering up to 50 MHz2 Channel – 4 Trace DisplayX 10 Magnification20ns max Sweep SpeedAlternate TriggeringVariable Hold Off & Line TriggeringUSB (Optional)
Microcontroller based oscilloscope, gives you feel of smooth digital touch. Digital readout backlit LCD displays Volts/Div. and Time/Div. settings when these controls are operated. Light weight and have sharp and bright trace. Vertical bandwidth is more than adequate and you can view signals up to 50MHz. The four trace features allows you to view original and expanded signals simultaneously for quick analysis.30 MHz BandwidthSharp Trace CRT and Auto focusComponent and Continuity TesterStable Triggering up to 50 MHz2 Channel – 4 Trace DisplayX 10 Magnification20ns max Sweep SpeedAlternate TriggeringVariable Hold Off & Line TriggeringUSB (Optional)
